Dimensions in detail: from length to boot capacity (2026)
The new Alfa Romeo Tonale 2026 measures 4,522 mm in length, 1,841 mm in width and 1,601 mm in height. The wheelbase is 2,636 mm. The boot offers a volume of 500 litres, which can be expanded to 1,550 litres with the rear seats folded down. The ground clearance is millimetres. This refers to the distance between the lowest point under the vehicle and the ground surface.
Exterior dimensions
| Length | 4,522 mm |
| Width (excluding mirrors) | 1,841 mm |
| Width (including mirrors) | 2,082 mm |
| Height | 1,601–1,614 mm |
| Wheelbase | 2,636 mm |
| Front overhang | 945 mm |
| Rear overhang | 941 mm |
| Turning circle | 11.54–11.57 m |
| Ground clearance | 141–156 mm |
Interior dimensions and boot volume
| Boot volume | 385–500 litres |
| Boot volume (rear seats folded) | 1,430–1,550 litres |
Differences between versions
The dimensions of the Alfa Romeo Tonale 2026 vary depending on the version. Below you will find the specific technical specifications.
| Fuel type | Version |
|---|---|
| Diesel | Dimensions Tonale Diesel 130 hp |
| Hybrid | Dimensions Tonale Ibrida 175 hp |
| Plug-in hybrid | Dimensions Tonale Ibrida Plug-in Q4 270 hp AWD |
More information
Comparison of Alfa Romeo model dimensions
Below is a comparison of the dimensions of the Tonale with other Alfa Romeo models in the same segment, as well as with slightly larger and smaller models available in 2026.
| Model | Length in mm | Width in mm | Height in mm | Boot in litres |
|---|---|---|---|---|
| Alfa Romeo Junior | 4,173 | 1,781 | 1,539 | 415 |
| Alfa Romeo Tonale | 4,522 | 1,841 | 1,601 | 500 |
| Alfa Romeo Stelvio | 4,687 | 1,903 | 1,693 | / |
Frequently Asked Questions
What are the dimensions of the new Alfa Romeo Tonale?
The Alfa Romeo Tonale measures 4,522 mm in length, 1,841 mm in width, and 1,601 mm in height. The wheelbase measures 2,636 mm.
What is the boot capacity of the Alfa Romeo Tonale?
The boot offers 500 litres of space and can expand to a maximum of 1,550 litres when the rear seats are folded down.
What is the turning circle of the Alfa Romeo Tonale?
The Alfa Romeo Tonale has a turning circle of 11.57 meters. This is the minimum space required to make a full 360-degree turn.
What is the ground clearance of the Alfa Romeo Tonale?
The Alfa Romeo Tonale has a ground clearance of 156 millimetres. This refers to the distance between the lowest point of the vehicle and the road surface.
