Dimensions in detail: from length to boot capacity
The BMW iX from 2021, 2022, 2023 and 2024 measures 4,953 mm in length, 1,967 mm in width and 1,695 mm in height. The wheelbase is 3,000 mm. The turning circle is 12,8 metres. This is the minimum space the vehicle needs to perform a 360-degree turn. The ground clearance is 202 mm. This is the distance between the lowest point under the vehicle and the road surface.
Exterior dimensions
| Length | 4,953 mm |
| Width (excluding mirrors) | 1,967 mm |
| Height | 1,695–1,696 mm |
| Wheelbase | 3,000 mm |
| Front track | 1,677–1,679 mm |
| Rear track | 1,706–1,709 mm |
| Turning circle | 12.8 m |
| Front tires | 235/60 R20 108H XL |
| Rear tires | 235/60 R20 108H XL |
| Ground clearance | 202–203 mm |
Differences between versions
The dimensions of the BMW iX from 2021, 2022, 2023 and 2024 vary depending on the version. Below you will find the specific technical specifications.
| Fuel type | Version |
|---|---|
| Electric | Dimensions iX xDrive40 326 hp AWD |
| Electric | Dimensions iX xDrive50 523 hp AWD |
