Discover all the dimensions of the BMW i3 from 2013, 2014, 2015, 2016 and 2017, including length, width, height, headroom, legroom, boot capacity, turning circle, ground clearance, tyre dimensions and much more.
Dimensions in detail: from length to boot capacity
The BMW i3 from 2013, 2014, 2015, 2016 and 2017 measures 3,999 mm in length, 1,775 mm in width and 1,578 mm in height.
The wheelbase is 2,570 mm.
The boot offers a volume of 260 litres, expandable to 1,100 litres with the rear seats folded down.
The turning circle is 9.86 metres. This is the minimum space the vehicle needs to perform a 360-degree turn.
The ground clearance is 140 mm. This is the distance between the lowest point under the vehicle and the road surface.
Exterior dimensions
| Length |
3,999 mm |
| Width (excluding mirrors) |
1,775 mm |
| Height |
1,578 mm |
| Wheelbase |
2,570 mm |
| Front overhang |
707 mm |
| Rear overhang |
722 mm |
| Turning circle |
9.86 m |
| Front tires |
155/70 R19 |
| Rear tires |
155/70 R19–175/65 R19 |
| Ground clearance |
140 mm |
Interior dimensions and boot volume
| Boot volume |
260 litres |
| Boot volume (rear seats folded) |
1,100 litres |
Differences between versions
The dimensions of the BMW i3 from 2013, 2014, 2015, 2016 and 2017 vary depending on the version. Below you will find the specific technical specifications.
